Como fazer viewport em Polyline?

Como fazer viewport em Polyline?

Selecione uma polilinha fechada ou um círculo no layout. (opção) Para criar uma viewport não-retangular (recortada), faça um dos seguintes: Escolha Poligonal no menu prompt. Digite P na linha de comando, e pressione Enter.

How can I convert a polyline to a viewport?

On the Layouts tab, click ‘Clip’ in the viewport panel, select the rectangular viewport, then click the polyline to convert. AutoCAD should have converted the polyline to a viewport and deleted the rectangular viewport you selected first. This entry was posted in AutoCAD and tagged polyline, viewport.

How to convert a closed object into a layout viewport?

With the Object option, you can select a closed object, such as a circle or closed polyline created in paper space, to convert into a layout viewport. The object that defines the viewport boundary is associated with the viewport after the viewport is created.

How to create a new viewport with nonrectangular boundaries?

You can create a new viewport with nonrectangular boundaries by converting a geometric object created in paper space into a layout viewport using the MVIEW or -VPORTS command. With the Object option, you can select a closed object, such as a circle or closed polyline created in paper space, to convert into a layout viewport.

How to create a nonctangular layout viewport in AutoCAD?

To translate this article, select a language. You can create a new viewport with nonrectangular boundaries by converting a geometric object created in paper space into a layout viewport using the MVIEW or -VPORTS command.
